callous Inclinometer (MODBUS RTU Protocol ）

Application: Solar photovoltaic power generation angle tracking system,

Military applications, Marine applications, Railway applications, whenever required accurate angle measurements & accurate electronic spirit leveling sys.

Standard reference

• Enterprise quality system standards: ISO9001: 2015 standard,

  (Certification number:  89210)

• CE certification: AT011611741E FCC certification: AT011611742E
• Tilt sensor production standards: GB / T 191 SJ 20873-2003 inclinometer general specification of Level

• Ronar metrology and quality inspection Calibrated in accordance to: JJF1119-2004 Electronic Level calibration.

Specification

• Product environmental testing standards: GJB150
• Electromagnetic anti-interference test standards: GB / T 17626
• Version: Ver.101

General Description

YOI726S-15-M485-MB is a small volume high- accuracy gradient inclinometer  that was converted to work in difficult areas by hardening the electromechanical mechanisms, Performed by,  "Yosi Ovadia" electrical marine  Engineering Ltd company

The inclinometer was adapted for military and other industries field control, using RS485/RS232 Serial interface, MODBUS RTU standard protocol format. Built-in high-precision 24bit A /D differential converter, by 5 filtering algorithms, which can measure the angle of sensor output relative to the horizontal tilt and pitch tilt. The product integration of the latest technology to the main MEMS tilt unit, measuring a range of ±180 degrees with full-range accuracy of 0.01 degrees, can easily achieve biaxial and uniaxial inclination measurement. The products are truly industrial-grade products, with reliable performance, scalability, and a variety of output options. The utility model is suitable for the control of the angle of the photovoltaic cell board, the orientation of the photovoltaic cell board, the measurement of the angle of various thermal power generation mirrors, and the large range of high precision measurements of industrial sites.

Features:

• Single/Dual Axis Inclinometer
• Accuracy: Refer to the technical data
• Wide temperature working: -40～+85℃
• IP67 protection class
• Direct lead cable interface
• Output mode: MODBUS
• Measuring Range :±1～±90° optional
• Wide voltage input: 9～36V
• Resolution: 0.001°
• Highly anti-vibration performance >100g
• Small size : 54×44×18mm（customized

Application:

• Satellite positioning Search
• engineering mechanical measurement of dip angle
• Radar detection of vehicle platform
• Gun Barrel angle measurement in early shooting
• Satellite communications vehicle posture detection
• Ship’s navigation posture measurement
• Rail-mobile monitoring
• oil-well drilling equipment
• Underground drill posture navigation
• Based on the angle direction measurement
• Shield pip jacking application
• Geological equipment inclined monitoring
